• F (ins) 1 1/8 F (mm) 28
• G (ins) 3/4 G (mm)
• 19 Hole Ø (ins) 1/2
• Hole Ø (mm) 12
• Material EN8 Steel
• Overall length (ins) 5 7/8
• Overall length (mm) 149
• Pin Type Implement Attachment
• Pin Ø (ins) 1-1/8 Pin Ø (mm)
• Tariff Code 7319909000
• Thread length (mm) 54
• Thread size 3/4''
• Thread type UNF
• Working length (ins) 2-3/8
• Working length (mm) 60
